Inside Cloudflare’s AI-Powered Firewall: New Features Revealed

Organizations faced a staggering 209 billion cyber threats daily during 2024’s first quarter – an 86.6% jump from last year. Cloudflare’s firewall AI adds a new protection layer that identifies and blocks attacks on Large Language Models (LLMs) and critical applications.

The system builds on Cloudflare’s strong Web Application Firewall (WAF) that handles 57 million HTTP requests every second. The security challenges have become more complex, with 4.5 million unique DDoS attacks blocked in Q1 2024. API traffic now makes up 60% of all network activity, and attackers exploit vulnerabilities within 22 minutes after finding them. This AI-powered security upgrade comes at a vital time for enterprise protection.

This piece gets into the core architecture, capabilities, and real-life effect of Cloudflare’s AI-powered firewall system. You will gain a detailed understanding of how it boosts application security in today’s fast-changing threat landscape.

Core Architecture of Cloudflare’s AI Firewall

Cloudflare’s AI-powered firewall works through a sophisticated architecture that handles an average of 11 million requests per second. A network of microservices forms the system’s foundation, which employs advanced technologies for data processing and threat detection.

Neural Network Design for Threat Detection

CatBoost, an advanced open-source library for gradient boosting on decision trees, sits at the heart of the threat detection system. The neural network processes both categorical and numerical features from request attributes and inter-request features. Multiple CatBoost models run at the same time on Cloudflare’s edge in shadow mode. One model stays in active mode to influence the final security score.

Real-time Processing Pipeline

The processing pipeline uses various technologies to achieve optimal performance:

• Data Processing Infrastructure: Uses Kafka, ClickHouse, Postgres, Redis, and Ceph for strong data management
• Development Framework: Uses Go, Rust, Python, and Java programming languages
• Deployment Architecture: Runs through Docker, Kubernetes, Helm, and Mesos/Marathon

After that, the system processes data from edge data centers and creates information needed for bot detection mechanisms. The Bot Management module runs on every machine at Cloudflare’s edge locations and analyzes requests immediately during processing.

Integration with Existing WAF Rules

The firewall naturally merges with Cloudflare’s existing WAF infrastructure to provide detailed security coverage. The system gives each prompt a score between 1 and 99 that indicates the likelihood of an injection attack. It analyzes inbound prompts for potential abuse and can run in front of models hosted on the Cloudflare Workers AI platform or third-party infrastructure.

This integration enables several key security actions:

• Automated Detection: Scans and assesses prompts submitted by users to identify exploitation attempts
• Real-time Protection: Runs close to the end user to provide immediate protection against model abuse
• Comprehensive Analysis: Combines traditional WAF tools with new protection layers specifically designed for LLM security

The system generates a bot management score for each request. Security teams can use this score to create custom rules and determine appropriate actions based on threat levels. This architecture protects against both traditional cyber threats and emerging AI-specific vulnerabilities.

Key Capabilities of the New AI Engine

Cloudflare’s firewall now features a new AI engine that excels at advanced threat detection and automated security management. Each day, the system handles 66 million potentially harmful requests, showcasing its strong defensive capabilities.

Pattern Recognition System

A sophisticated heuristics-based pattern recognition system identifies malicious AI bots and unauthorized access attempts. The system achieves higher accuracy in threat identification by combining traditional detection methods with AI-powered analysis. Pattern recognition capabilities include:

• User-submitted prompts undergo scanning to detect exploitation attempts
• Specialized signature analysis catches prompt injection attacks
• The system spots attempts to extract sensitive data from AI models

Security teams can create targeted rules based on predefined categories thanks to specific tags assigned to each analyzed prompt. This tagging system gives teams granular control over prompts that reach AI models.

Automated Rule Generation

Security management has reached new heights with the AI Assistant for WAF Rule Builder. Security teams can now generate custom rules using natural language prompts. A user who types “Match requests with low bot score” will see the system create corresponding security rules automatically.

Several advanced features make the automated rule generation system stand out:

• Threats get blocked immediately without human intervention, with responses coming from locations near end users
• The system works seamlessly with existing WAF infrastructure to provide detailed security coverage
• Every API request containing LLM prompts undergoes automatic scanning to detect potential threats

The engine goes beyond simple rule creation with a sophisticated scoring system that reviews each prompt’s potential maliciousness. This scoring mechanism works with the pattern recognition system to create multiple layers of security.

Cloudflare’s global network powers the AI engine’s defensive capabilities, enabling quick threat detection and response. The system identifies and blocks emerging threats almost instantly while adapting to new attack patterns.

Threat Detection Mechanisms

Cloudflare’s threat detection mechanisms create a multi-layered defense system that processes 55 million HTTP requests per second. The system uses advanced detection techniques in security domains of all types to protect against emerging threats.

Zero-day Attack Prevention

Cloudflare’s WAF Attack Score system identifies potential threats proactively before they become known vulnerabilities. The scoring mechanism ranges from 1 to 99, with scores below 20 showing malicious activity. The system proved effective when it detected and blocked the Ivanti Connect Secure vulnerability exploits before their public disclosure.

Bot Traffic Analysis

The system implements five complementary detection mechanisms to analyze bot traffic. Machine learning models and behavioral analysis help Cloudflare identify bot patterns by analyzing trillions of requests flowing through its network weekly. The platform’s detection capabilities include:

• Supervised ML models for threat classification
• Behavioral analysis for pattern recognition
• Heuristics engine for straightforward bot identification
• Challenge-response systems for verification
• Fingerprinting techniques for bot identification

API Abuse Detection

The API protection system uses Schema Validation to create a positive security model based on API contracts. Each request gets evaluated against predefined schemas, and the system logs or blocks non-compliant traffic. Requests containing extraneous input or potentially malicious payloads trigger immediate action to protect the origin.

DDoS Attack Mitigation

The DDoS protection infrastructure has 348 Tbps of network capacity, which surpasses the largest recorded DDoS attack by 23 times. The mitigation process follows four significant stages:

1. Detection phase using IP reputation and common attack patterns
2. Response mechanisms for intelligent traffic filtering
3. Smart routing to break traffic into manageable chunks
4. Adaptation through continuous analysis of attack patterns

The system operates in more than 335 cities worldwide and mitigates attacks from the nearest location without routing traffic to distant scrubbing centers. This distributed approach will give a protection across OSI layers 3, 4, and 7, safeguarding web applications, TCP/UDP applications, and networks alike.

You can find our article here to configure these settings

Performance Benchmarks

Cloudflare’s WAF machine learning models show remarkable improvements in speed and accuracy based on recent standards. Their optimization work has produced exceptional results across many performance metrics.

Response Time Analysis

The WAF ML models achieved a dramatic 5.5x speed boost. The execution time dropped from 1519 to 275 microseconds. Several vital optimizations made this possible:

• TensorFlow Lite upgrade from 2.6.0 to 2.16.1 cut model inference time by 77.17%
• SIMD optimizations and XNNPack implementation reduced processing time by four-fold
• Branchless ngram lookups and loop unrolling ran six to twelve times faster than the baseline implementation

The system works faster now because the firewall sits ahead of LLMs on Cloudflare’s Workers AI platform. This setup gives minimal latency and immediate threat protection. The team reduced the connection between processing time and input size, which led to substantial performance gains.

False Positive Reduction Stats

The improved AI engine detects threats with remarkable accuracy while keeping false positives low. The system achieved these notable improvements:

Test datasets showed an 80% decrease in false positive rates. The system still maintains high detection accuracy – 97.5% of client-provided test sets correctly identified XSS/SQLi attacks.

The WAF excels at pattern recognition in:

• JSON-esque and XML/SOAP-esque content with false positives down to 1/100,000 from 1/50
• SQL-structured analogs with far fewer false positives
• Highly fuzzed content with better true positive detection rates

The system accurately spots malicious content in complex scenarios and larger payloads. A six-byte payload hidden in a 100-kilobyte string can’t escape detection. The WAF Attack Score system works with high precision – scores below 20 point to malicious activity.

Conclusion

Ground implementation results prove these performance metrics. During the Ivanti Connect Secure vulnerability incident, WAF rules triggered more than 180,000 times. This shows both accuracy and protection at scale.

These standards highlight the system’s ability to handle tens of millions of requests per second with high accuracy. Speed and precision improvements make Cloudflare’s WAF a resilient defense mechanism against emerging threats.

Cloudflare’s AI-powered firewall serves as a resilient defense system against modern cyber threats. The system processes 57 million HTTP requests per second. Its sophisticated architecture shows it can handle enterprise-scale security challenges well.

Tests reveal remarkable improvements in performance. The execution times dropped from 1519 to 275 microseconds while false positive rates fell by 80%. These changes save roughly 32 years of processing time each day, making the system quick and dependable.

Ground implementations like Alpargatas’ success story validate the WAF’s effectiveness in protecting digital assets for companies of all sizes. The system detected and blocked emerging threats before public disclosure during the Ivanti Connect Secure ordeal. This highlights its proactive security approach.

The detailed protection goes beyond traditional threats and tackles modern challenges like API security and LLM-specific vulnerabilities. Security teams can now use automated scanning, immediate threat blocking, and smooth integration with existing infrastructure.

We invite you to keep up with the latest cybersecurity developments. You can follow our social platforms to learn about emerging security technologies and best practices.

Cloudflare’s AI-powered firewall marks a key advancement in application security. It combines speed, accuracy, and detailed protection to tackle today’s complex threat landscape.
